Product images are for reference only. Please review product specifications for the most accurate and detailed information.

Leeson X912

Leeson
1HP 1725 56 TENV 115V|230V Farm Duty
Catalog Number: X912
Part Number: 056B17T5303
HP
1
RPM
1800
Voltage
115V,230V
Frame
56
Phase
1
Enclosure
TENV
Material
Rolled Steel
Mounting
Rigid

NO STOCKING INFORMATION AVAILABLE

See from other brands that have matching specifications to this product.

Technical Support Available 8:30am-6:00pm EST

Call 1-800-890-7593

Contact our team for alternative solutions

No product line matches have been found, but our team may be able to help find an alternate solution.

Description

Designed for demanding agricultural belt drive fan applications such as poultry house fans and barn exhaust fans. Totally Enclosed Air Over models must be mounted within the airstream for proper cooling.

Feature

  • Suitable for belted loads
  • Ball bearings
  • Continuous duty
  • Automatic reset thermal protector
  • Fully gasketed
  • UL recognized and CSA certified
Electrical Data
Rated Motor Output Power
1 HP
.75 kW
Rated Motor Speed
1725 RPM
Rated Motor Voltage
115V,230V
Rated Motor Current
9.2/4.6 AMP
Phase
1
Poles
4
Locked Rotor Current
-
Fl Current @ 208V
-
Service Factor
1
KVA Code
K
Nominal Efficiency
81.1
Nominal Power Factor
86.2
Leads (Qty, Size)
-
Frequency
60 Hz
Connection
-
Start Capacitor
-
Run Capacitor
-
MFD
-
VFD (S.F. 1.0)
Ratio
Hz
Variable Torque
-
-
Constant Torque
-
-
General Data
Frame
56
Enclosure
TENV
Mounting
Rigid
Number of Speeds
-
Approximate Weight
32lb
Double Drilled
No
Frame Material
Rolled Steel
C-Dimension
33.86"
NEMA Design
N
Degree of Protection (IP)
IP43
Insulation Class
B
Rotation
Reversible
Duty
Continuous
Conduit Box Location
-
Removable Feet
No
Orientation
Horizontal
Ambient Temp
40°C
Full Load Temperature Rise
Full Load Temp Rise
-
Temp Code
-
Mechanical Data
DE Bearing
6203
NDE Bearing
6203
Shaft Diameter
0.625"
Shaft Length
2.32"
Grease Type
-
Greaseable
No
Hazardous Locations
CSA Certified
-
Temp Code (Sine Wave Power)
-
Temp Code (VFD Power)
-
Additional Information
Agency Approvals
CSA & UL
Country of Origin
-
Warranty
1-Year
