Nidec 5462H

Nidec · Permanent Split Capacitor Condenser Fan 5.6" Diameter TEAO
1/3 HP 1075 48Y Fr TEAO 208-230V Permanent Split Capacitor Capacitor Included: TOCF5
Catalog Number: 5462H
Model Number: K055CLF0586012B
HP
1/3
RPM
1200
Voltage
208-230V
Frame
48Y
Phase
1
Enclosure
TEAO
Material
Rolled Steel
Mounting
Stud

Product-line overview

Lower your energy usage and increase the reliability of your HVAC system. With horsepower ranging from ¼ to 5 HP, these motors are available for OEM original and replacement applications. When you want to keep your indoor atmosphere at its most comfortable, choose a Nidec HVAC motor.

NO STOCKING INFORMATION AVAILABLE

See from other brands that have matching specifications to this product.

Technical Support Available 8:30am-6:00pm EST

Call 1-800-890-7593

Alternatives

This item has similar horsepower, RPM, voltage, frame size, phase, enclosure, and mounting and may be used as an alternative for the following motors:

BrandCatalog
CENTURY ORM5458BF, FE6000F
EMERSON1860H, 3323H, 1859H, 1861H, 1859, K055CLF0673012B, K55CLF-586, K055WRG0121012B, K055WEH0625012B, K055WEG0624012B, K055WGK0951012B, 5458H, 5430, K055LMJ2478012B, K55LGE-5804, K055WRH0122012B, K055WRF0120012B, K055WNB1306012B
US MOTORS1859PEP, 1860PEP, 1861PEP
AO SMITH FE6000F
GENTEQ 6303
GLOBAL IND WBB468145
JS S81-133
MARS 20465
ROTOM M2-R22605
SMITH 0RM5458BF
UPG FHM3465HT

Nidec Rescue Condenser Fan

Applications

Commercial and Residential Condensing Units.

Can replace a range of horsepower application and a variety of mounting styles.

Features

  • High 158°F (70°C) Or 140°F (60°C) Ambient Designs
  • Automatic Reset Thermal Overload Protector
  • Designed For Use With 370V Capacitors
  • Special Treated Rotor For Corrosion Protection
  • Includes Lead End Mounting Holes For RHEEM® TRANE® Units
  • 48" Leads
  • Extended Mounting Studs
  • Ball Bearings
  • Reversible Rotation
  • High Efficiency Design
  • Continuous Duty, Air Over
Electrical Data
Rated Motor Output Power
1/3 HP
.25 kW
Rated Motor Speed
1075 RPM
Rated Motor Voltage
208-230V
Rated Motor Current
2.6-1.8 AMP
Phase
1
Poles
6
Locked Rotor Current
-
Fl Current @ 208V
2.6
Service Factor
1
KVA Code
D
Nominal Efficiency
-
Nominal Power Factor
-
Leads (Qty, Size)
-
Frequency
60 Hz
Connection
-
Start Capacitor
-
Run Capacitor
-
MFD
5
VFD (S.F. 1.0)
Ratio
Hz
Variable Torque
-
-
Constant Torque
-
-
General Data
Frame
48Y
Enclosure
TEAO
Mounting
Stud
Number of Speeds
4 Speed
Approximate Weight
18.1lb
Double Drilled
No
Frame Material
Rolled Steel
C-Dimension
9.6"
NEMA Design
-
Degree of Protection (IP)
-
Insulation Class
F
Rotation
Reversible
Duty
-
Conduit Box Location
-
Removable Feet
No
Orientation
-
Ambient Temp
70°C
Full Load Temperature Rise
Full Load Temp Rise
-
Temp Code
-
Mechanical Data
DE Bearing
BALL
NDE Bearing
BALL
Shaft Diameter
0.5"
Shaft Length
1.5"
Grease Type
-
Greaseable
No
Hazardous Locations
CSA Certified
-
Temp Code (Sine Wave Power)
-
Temp Code (VFD Power)
-
Additional Information
Agency Approvals
CSA, UL & CE
Country of Origin
-
Warranty
1-Year
