Product images are for reference only. Please review product specifications for the most accurate and detailed information.

Leeson K608A

Leeson
1 HP 1760 56C TEFC 230V|460V General Purpose
Catalog Number: K608A
Part Number: 056T17W99021
HP
1
RPM
1800
Voltage
230V,460V
Frame
56C
Phase
3
Enclosure
TEFC
Material
Rolled Steel
Mounting
C-Face / Round Body

Availability: Factory Order (3-5 weeks)

Available for Delivery

To get accurate delivery estimates, please enter your zip code.

Important Links

Technical Support Available 8:30am-6:00pm EST

Call 1-800-890-7593

Contact our team for alternative solutions

No product line matches have been found, but our team may be able to help find an alternate solution.

Feature

  • 303 Stainless steel shafts with contact lip seal & V-ring slinger
  • Rolled steel construction
  • Gray epoxy paint
  • Class F insulation
  • Automatic thermal protection
Electrical Data
Rated Motor Output Power
1 HP
.75 kW
Rated Motor Speed
1760 RPM
Rated Motor Voltage
230V,460V
Rated Motor Current
3.2/1.6 AMP
Phase
3
Poles
4
Locked Rotor Current
-
Fl Current @ 208V
-
Service Factor
-
KVA Code
N
Nominal Efficiency
-
Nominal Power Factor
68.5
Leads (Qty, Size)
-
Frequency
60 Hz
Connection
-
Start Capacitor
-
Run Capacitor
-
MFD
-
VFD (S.F. 1.0)
Ratio
Hz
Variable Torque
-
-
Constant Torque
-
-
General Data
Frame
56C
Enclosure
TEFC
Mounting
C-Face / Round Body
Number of Speeds
-
Approximate Weight
36lb
Double Drilled
No
Frame Material
Rolled Steel
C-Dimension
12.87"
NEMA Design
B
Degree of Protection (IP)
-
Insulation Class
F
Rotation
Reversible
Duty
Continuous
Conduit Box Location
-
Removable Feet
No
Orientation
Horizontal
Ambient Temp
40°C
Full Load Temperature Rise
Full Load Temp Rise
-
Temp Code
-
Mechanical Data
DE Bearing
6203
NDE Bearing
6203
Shaft Diameter
0.625"
Shaft Length
2"
Grease Type
-
Greaseable
No
Hazardous Locations
CSA Certified
-
Temp Code (Sine Wave Power)
-
Temp Code (VFD Power)
-
Additional Information
Agency Approvals
CSA, UL & CE
Country of Origin
-
Warranty
1-Year
