Product images are for reference only. Please review product specifications for the most accurate and detailed information.

Leeson K555

Leeson
3/4 HP 1800 56J ODP 208-230V|460V Pump
Catalog Number: K555
Part Number: 5K46KN4141
HP
3/4
RPM
1800
Voltage
208-230V,460V
Frame
56J
Phase
3
Enclosure
ODP
Material
Rolled Steel
Mounting
C-Face / Round Body

Availability: Factory Order (3-5 weeks)

Available for Delivery

To get accurate delivery estimates, please enter your zip code.

Important Links

Technical Support Available 8:30am-6:00pm EST

Call 1-800-890-7593

Cross-Referenced Matches (1)

Equivalent alternatives from other brands that have matching specifications to this product.

Contact our team for alternative solutions

No product line matches have been found, but our team may be able to help find an alternate solution.

Feature

  • Double sealed ball bearings, mechanically locked on shaft end
  • Continuous duty
  • 56J = 416 stainless steel threaded shaft with slinger
  • UL recognized, CSA certified, and CE mark
  • Drip cover not included
Electrical Data
Rated Motor Output Power
3/4 HP
.55 kW
Rated Motor Speed
1800 RPM
Rated Motor Voltage
208-230V,460V
Rated Motor Current
3.3-3.0/1.5 AMP
Phase
3
Poles
4
Locked Rotor Current
-
Fl Current @ 208V
3.3
Service Factor
1.25
KVA Code
K
Nominal Efficiency
74
Nominal Power Factor
-
Leads (Qty, Size)
-
Frequency
60 Hz
Connection
-
Start Capacitor
-
Run Capacitor
-
MFD
-
VFD (S.F. 1.0)
Ratio
Hz
Variable Torque
-
-
Constant Torque
-
-
General Data
Frame
56J
Enclosure
ODP
Mounting
C-Face / Round Body
Number of Speeds
-
Approximate Weight
24lb
Double Drilled
No
Frame Material
Rolled Steel
C-Dimension
11.24"
NEMA Design
-
Degree of Protection (IP)
-
Insulation Class
B
Rotation
Reversible
Duty
Continuous
Conduit Box Location
-
Removable Feet
No
Orientation
Horizontal
Ambient Temp
40°C
Full Load Temperature Rise
Full Load Temp Rise
-
Temp Code
-
Mechanical Data
DE Bearing
6203
NDE Bearing
6203
Shaft Diameter
0.625"
Shaft Length
2.5"
Grease Type
-
Greaseable
No
Hazardous Locations
CSA Certified
-
Temp Code (Sine Wave Power)
-
Temp Code (VFD Power)
-
Additional Information
Agency Approvals
CSA & UL
Country of Origin
-
Warranty
1-Year
