Product images are for reference only. Please review product specifications for the most accurate and detailed information.

Leeson E265

Leeson
1/2 HP 1800 56C TEFC 100-120V|200-240V General Purpose
Catalog Number: E265
Part Number: 5KCR46MN0093
HP
1/2
RPM
1800
Voltage
100-120V,200-240V
Frame
56C
Phase
1
Enclosure
TEFC
Material
Rolled Steel
Mounting
C-Face / Round Body

Availability: Factory Order (3-5 weeks)

Available for Delivery

To get accurate delivery estimates, please enter your zip code.

Important Links

Technical Support Available 8:30am-6:00pm EST

Call 1-800-890-7593

Contact our team for alternative solutions

No product line matches have been found, but our team may be able to help find an alternate solution.

Feature

  • Ball bearingsmechanically locked on shaft end
  • Heavy gauge steel frame and base
  • Suitable for horizontal or vertical mounting
  • NEMA Service Factors
  • UL Recognized and CSA Certified
Electrical Data
Rated Motor Output Power
1/2 HP
.37 kW
Rated Motor Speed
1800 RPM
Rated Motor Voltage
100-120V,200-240V
Rated Motor Current
5.8-5.6/2.9-2.8 AMP
Phase
1
Poles
4
Locked Rotor Current
-
Fl Current @ 208V
2.9
Service Factor
1.25
KVA Code
N
Nominal Efficiency
74
Nominal Power Factor
83
Leads (Qty, Size)
-
Frequency
60 Hz
Connection
-
Start Capacitor
-
Run Capacitor
-
MFD
-
VFD (S.F. 1.0)
Ratio
Hz
Variable Torque
-
-
Constant Torque
-
-
General Data
Frame
56C
Enclosure
TEFC
Mounting
C-Face / Round Body
Number of Speeds
-
Approximate Weight
27lb
Double Drilled
No
Frame Material
Rolled Steel
C-Dimension
11.84"
NEMA Design
-
Degree of Protection (IP)
-
Insulation Class
B
Rotation
Reversible
Duty
Continuous
Conduit Box Location
-
Removable Feet
No
Orientation
Horizontal
Ambient Temp
40°C
Full Load Temperature Rise
Full Load Temp Rise
-
Temp Code
-
Mechanical Data
DE Bearing
6203
NDE Bearing
6203
Shaft Diameter
0.625"
Shaft Length
1.875"
Grease Type
-
Greaseable
No
Hazardous Locations
CSA Certified
-
Temp Code (Sine Wave Power)
-
Temp Code (VFD Power)
-
Additional Information
Agency Approvals
CSA & UL
Country of Origin
-
Warranty
1-Year
